KitchenAid 29 cu. ft. French Door Refrigerator with Exterior Water - KRMF436SJP

Top Features
Max Capacity Meets Premium Personalization
with a build made to fit your groceries and customizable storage spaces to make them easy to access.
Spacious Capacity at 29 cu. ft.
from this 4-door French Door Refrigerator makes room for every farmer's market haul and brings convenience with customizable storage spaces for your unique ingredients.
FreshChill™ Full-Width Refrigerated Drawer
delivers organization with removable storage dividers and allows you to set temperatures manually. Adjust your drawer to be wine storage (50°F), deli storage (37°F), drink storage (34°F) or meat storage (30°F) at the touch of a button.
Additional Features
Large Capacity Ice Storage
holds up to 4 lbs of ice and creates an extra half shelf of storage space. The ice bucket is also removable to make filling coolers easy for any adventure.
Designed To Be Personalized
with a curated palette of exterior finishes and mixed metal hardware. Pick from lush Juniper, warm Black Ore and classic Stainless Steel finishes, all with matching handles. Personalize your hardware with optional handle accessory kits in Brass, Bronze, Black Ore and Stainless Steel.
everydrop® Water Filter
is easy to install, replace, and use. This filter reduces 75 potentially harmful contaminants* like microplastics and lead while giving you clean, fresh-tasting water for recipes and drinks.
*Filters certified by NSF International under NSF/ANSI Standards 42, 53 and 401 to reduce specific contaminants. See Whirlpool.com for details.
Wood-Look Sliding Storage Tray
keeps serving platters and ingredients easily accessible. The tray pulls out for easy cleaning.
Large Capacity Ice Production
delivers over 3.5 lbs of filtered ice created per day. This convenient feature keeps up so you're well-prepared to meet the demands of your guests when hosting.
Preserva® Food Care System
helps keep ingredients fresh and flavorful. This single evaporator system uses sensors to continually monitor temperature levels in both the refrigerator and freezer and adapts the flow of cold air between them to maintain optimal temperatures throughout.
Crisper Bins with FreshSeal™ Technology
feature a gasket seal to help maintain optimal humidity levels to keep your ingredients fresh.
Produce Preserver
helps delay over-ripening to extend freshness of fruits and vegetables. This replaceable filter for crisper drawers absorbs the ethylene gas produced as part of the natural ripening process for up to 6 months.
Exterior Ice & Water Dispenser
fits glasses and measuring cups and dispenses filtered water and ice without having to open the refrigerator door.
Adjustable Glass Shelving
allows for personalized storage spaces so your most-used ingredients are always easy to find.
Easy-Access Freezer Bin
keeps small ingredients visible and within easy reach, ideal for ice cream, frozen fruits and dough portions. It's designed to keep your frozen ingredients organized, preventing the need to rummage through everything to find small items.
Gallon Door Bins
maximize storage with thoughtfully designed and adjustable bins, accommodating gallon jugs, large containers and bulky items with ease.
Standard Depth Design
delivers generous internal capacity to take on every grocery trip.
Ultra-Bright LED Lighting
turns on when the refrigerator or freezer door is open, making it easy to find items inside.
Max Cool
drops refrigerator temperature to coldest level within one hour to help chill groceries, beverages and ingredients for serving. After 2 hours, temperature will automatically be restored to previous setting.
Max Freeze
drops the left freezer compartment temperature to coldest level, so frozen goods can reach optimal temperatures. After 24 hours, the temperature will automatically be restored to the previous setting.
Pizza Storage
conveniently stores and organizes frozen pizzas in an easy-to-find, upright position.
Touch Panel Controls
on door exterior put refrigerator functions at your fingertips for quick and easy adjustments to temperature, ice maker, and water filter. Smooth, seamless design is easy to clean.
PrintShield® Finish
resists smudges and fingerprints. The specialized coating for stainless steel is easy to clean with just water and a soft cloth, so you can spend more time cooking and less time cleaning up.
Heavy-Duty Door and Hinges
have been rigorously tested to withstand years of use. Opened and closed 300,000 times, these hinges are in it for the long haul.
Custom Freezer Temperature Control
keeps frozen food at just the right temperature with multiple temperature settings, from frozen veggies and meat to keeping ice cream scoopable.
Automatic Ice Maker
ensures that you have a continuous supply of fresh, filtered ice for entertaining or everyday beverages and creations.
Vacation Mode
saves 5% of your refrigerator’s energy use while you are away. Always remove your perishable foods before choosing this setting.
Sabbath Mode (Star-K Certified)
to meet kosher requirements for use on the Jewish Sabbath and other religious holidays. Turning on Sabbath Mode disables the refrigerator's automatic lights and alarm tones.
| Dimensions | |
|---|---|
| Depth | 37.44 " |
| Width | 35.94 " |
| Height | 70.06 " |
| Carton Depth | 37.0 " |
| Carton Height | 74.0 " |
| Carton Width | 39.0 " |
| Gross Weight | 395.0 lbs |
| Net Weight | 364.0 lbs |
| Cutout Height | 70.19 " |
| Cutout Width | 36.19 " |
| Depth Closed Excluding Handles | 34.75 " |
| Depth Closed Including Handles | 37.44 " |
| Depth With Door Open 90 Degree | 49.0 " |
| Cabinet Width | 35.94 " |
| Depth Excluding Doors | 29.88 " |
| Height To Top Of Door Hinge | 70.06 " |
| Height To Top Of Cabinet | 69.0 " |
| Popular Height | 70 Inch Tall |
| Popular Width | 36 Inch Wide |
| Freezer compartment | |
| Door Bins | Pizza Pocket |
| Door Type | Pull-Out |
| Freezer Drawer Basket | 2 Full Width Plastic 2 Small Storage Bin Dividers |
| Light | Yes |
| Details | |
| Counter Depth | No |
| Cooling Type | Single Evaporator |
| Dispenser | |
| Dispenser Type | Exterior Ice and Water |
| Types Of Ice | Cubed |
| Exterior | |
| Cabinet Color | Juniper Green |
| Cabinet Finish | Textured |
| Door Finish | Smooth |
| Door Style | Contour |
| Hidden Hinge | Yes |
| Number Of Doors | 4 |
| Reversible Door | N/A |
| Handle Color | Juniper |
| Handle Material | Metal |
| Handle Type | Reach-Through Handle |
| Filters | |
| Fresh Flow Air Filter Included | No |
| Produce Preserver | Yes |
| Water Filter Location | Interior |
| Water Filter Part Number | EDRARXD1 |
| Icemaker | |
| Icemaker Location | Refrigerator Door |
| Refrigerator compartment | |
| Conventional Shelves | 1 Adjustable Full-Width Glass 1 Slide-Out - Wood Finish 2 Adjustable Half Width |
| Door Bins | 1 Adjustable Gallon 1 Fixed Full-Width 2 Fixed Gallon Extra Cold Bin Full Width |
| Humidity Controlled Drawers | No |
| Lighting | LED |
| Liner Finish | Platinum |
| Non Climate Control Drawers | 2 Half-Width |
| Number Of Interior Shelves | 4 |
| Pantry Drawer | Yes |
| Temperature Controlled Drawers | 1 Full-Width |
| Specifications | |
| Optional Accessories | EDRARXD1B |
| Aesthetic | New Design |
| Ebl Accessories | W11777156 |
| Customizable | Yes |
| Country Of Origin | China |
| Launch Date | December 2025 |
| Extended Service Plan Parent | EW08IW1Y, EW08IW2Y, EW08IW4Y |
| Fingerprint Resistant | No |
| Certifications | |
| Cee Tier | Tier I |
| Energy Star Qualified | Yes |
| UL | Yes |
| Star K Certified | Yes |
| CONTROLS | |
| Control Location | Side Door |
| Control Lockout | Yes |
| Door Ajar Open Alarm | Yes |
| Max Cool Fast Cool | Yes |
| Sabbath Mode | Yes |
| Water Filter Indicator Reset | Yes |
| Electrical | |
| Amps | 20 |
| Volts | 115 |
| AHAM Volumes And Shelf Area | |
| Freezer Volume Cu Ft | 9.01 |
| Refrigerator Volume Cu Ft | 19.73 |
| Total Volume Cu Ft | 28.74 |
| Configuration | |
| Installation Configuration | Freestanding |
| Description | |
| Type Of Refrigerator | French Door |
